Description
KEY PERFORMANCE FACTORS
| Sizes | S |
| Colours |
Ultra Navy
|
| Frame |
ALUXX-grade aluminum, disc
|
| Fork |
high-tensile steel, rack mount, disc
|
| Shock |
N/A
|
| Handlebar |
Giant Sport XC, 31.8mm XS:60cm, S:64cm, M:64cm, L:68cm, XL:68cm
|
| Grips |
Giant Sole-O
|
| Stem |
Giant Sport, 15-degree, 25.4mm XS:75mm, S:90mm, M:90mm, L:90mm, XL:105mm
|
| Seatpost |
Giant D-Fuse, alloy XS:300mm, S:300mm, M:350mm, L:350mm, XL:350mm
|
| Saddle |
Giant ErgoContact
|
| Pedals |
Giant Urban Fitness
|
| Shifters |
Shimano Altus, 2×8
|
| Front Derailleur |
Shimano FD-TY606
|
| Rear Derailleur |
Shimano RD-TY310
|
| Brakes |
Tektro hydraulic, Giant MPH rotors [F]160mm, [R]160mm
|
| Brake Levers |
Tektro
|
| Cassette |
Shimano CS-HG318, 11×34
|
| Chain |
KMC Z8.3
|
| Crankset |
forged alloy, 30/46 XS:170mm, S:170mm, M:170mm, L:172.5mm, XL:175mm
|
| Bottom Bracket |
cartridge
|
| Rims |
Giant double wall aluminum
|
| Hubs |
alloy, 32h
|
| Spokes |
stainless, 14g
|
| Tires |
Giant S-X3, puncture protect, 700x38c
|
|
Extras
|
45mm max tire size
|
|
Weight
|
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
|
Download PDF
Additional information
| color | Black, Blue, Red |
|---|
SIZING GUIDE AND GEOMETRY
| A | SEAT TUBE LENGTH (mm) | 185 |
| B | SEAT TUBE ANGLE | 73.0° |
| C | TOP TUBE LENGTH (mm) | 302 |
| D | HEAD TUBE LENGTH (mm) | 90 |
| E | HEAD TUBE ANGLE | 71.0° |
| F | FORK RAKE (mm) | 35 |
| G | TRAIL (mm) | 80.7 |
| H | WHEELBASE (mm) | 614 |
| I | CHAIN STAY LENGTH (mm) | 257 |
| J | BOTTOM BRACKET DROP (mm) | 28 |
| K | STACK (mm) | 287 |
| L | REACH (mm) | 214 |
| M | STAND OVER HEIGHT (mm) | 344 |
| N | HANDLEBAR WIDTH (mm) | 470 |
| O | STEM LENGTH (mm) | 40 |
| P | CRANK LENGTH (mm) | 89 |
| Q | WHEEL SIZE | 12″ |
TECHS & FEATURES
