Description
THE TRAIL IS CALLING, AND HERE’S YOUR ANSWER. THIS BALANCED, SMOOTH-RIDING E-BIKE GIVES YOU A SMOOTH BOOST OF POWER AND TOTAL CONTROL, SO YOU CAN HAVE MORE FUN AND EXPAND YOUR OFF-ROAD RIDING CAPABILITIES.
KEY PERFORMANCE FACTORS
Smooth power delivery
The SyncDrive Core motor technology delivers smooth, instantaneous power to conquer all kinds of terrain and have more fun.
Balanced, confident handling
Lightweight aluminum frame with trail-friendly geometry, 100mm of front suspension travel, and stable 29-inch wheels with tubeless tires puts you in control on off-road terrain.
Long-lasting battery
Side Release EnergyPak with 400Wh of capacity is easy to charge with our 4A smart charger.
RANGE
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
ENERGYPAK SMART 375 / SYNCDRIVE PRO
Range Extreme: 55 KM Good: 105 KM Ideal: 150 KM
| Motor | SyncDrive Core, 50Nm, Powered by Yamaha |
| Sensor | RideControl Dash, full color LCD screen |
| Display | RideControl Dash, full color LCD screen |
| Battery | EnergyPak 400Wh |
| Sizes | S.M |
| Color | Metallic Blue |
| Frame | ALUXX Aluminum, Overdrive 1½ – 1⅛” head tube, integrated KS18 kickstand mount |
| Fork | SR Suntour XCM ATB Coil 29″ 100mm travel, Tapered 1½ – 1⅛” steerer |
| Handlebar | Giant Connect TR Riser 31.8×690~750mm |
| Stem | Giant Contact |
| Setpost | Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium |
| Saddle | Giant Sport |
| Pedals | Aluminum Platform |
| Shifters | Shimano Altus |
| Brake Levers | RS360A |
|
Rear Derailleur
|
Shimano Alivio, 9-speed |
| Brakes | Tektro HD-M275, hydraulic disc, 160/180mm |
| Brake Levers | Tektro HD-M275 |
| Cassette | Shimano CS-HG200, 11-36T, 9-speed |
| Chain | KMC e.9 Sport, e-bike optimized |
| Crankset | FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T |
| Rim | Giant GX03V |
| Hubs | Giant eTracker Sport, [F] 9mm QR [R] 135mm QR |
| Spokes | Stainless steel |
Tires Maxxis Rekon 29×2.4″ Wire Bead 60TPI
Extras Giant EnergyPak 6A fast charger
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
Download PDF
Additional information
| color | Black, Blue, Red |
|---|
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.Available sizes may vary from country to country.
| S | ||
| A | SEAT TUBE LENGTH (mm) | 405 |
| B | SEAT TUBE ANGLE | 73.0° |
| C | TOP TUBE LENGTH (mm) | 575 |
| D | HEAD TUBE LENGTH (mm) | 105 |
| E | HEAD TUBE ANGLE | 68° |
| F | FORK RAKE (mm) | 46 |
| G | TRAIL (mm) | 100.7 |
| H | WHEELBASE (mm) | 1141 |
| I | CHAIN STAY LENGTH (mm) | 475 |
| J | BOTTOM BRACKET DROP (mm) | 45 |
| K | STACK (mm) | 625 |
| L | REACH (mm) | 384 |
| N | HANDLEBAR WIDTH (mm) | 723 |
| O | STEM LENGTH (mm) | 50 |
| P | CRANK LENGTH (mm) | 160 |
| Q | WHEEL SIZE | 29″ |
