ANTHEM ADVANCED PRO 29 0

Description

THIS PRO-LEVEL XC FLYER PAIRS NEW FLEXPOINT PRO REAR SUSPENSION WITH A SUPERLIGHT FULL COMPOSITE FRAME AND RACE-READY GEOMETRY. IT’S THE ULTIMATE WEAPON FOR TECHNICAL CROSS-COUNTRY TERRAIN.

Ultra-efficient

Next-generation Advanced composite mainframe and rear swingarm is 250g lighter than previous version. The bottom bracket area is stiffer for faster acceleration, and a steeper seattube puts the rider in an efficient, front-forward climbing position.

Superior control

All-new FlexPoint Pro suspension delivers 100mm of smooth, active rear travel. The reengineered frameset features modern XC geometry including a slacker 67.5-degree headtube and 110mm suspension fork for technical descents.

29er stability and speed

Frame geometry and suspension are optimized for larger-diameter 29-inch wheels. A longer reach and updated cockpit including a 35mm composite handlebar and alloy stem further boost balance and stability on XC terrain.

HIGHLIGHTS

Engineered with a full composite frameset, this 29er has 100mm of rear suspension travel and 110mm up front. The linkage-driven, single-pivot FlexPoint Pro rear suspension makes room for shorter chainstays to improve climbing capabilities and overall agility. Other updates include new 29er-specific XC race geometry with a longer reach and a slacker headtube angle plus a lightweight, stiff composite wheelset for quick, precise handling.

Sizes
S, M,
Colors Raw Carbon / Chrome
Frame Advanced-Grade Composite front and rear triangles, 100mm FlexPoint Pro suspension, 12x148mm thru-axle
Fork Fox 34 Float SC Factory Live Valve, 110mm, FIT4 damper, Boost 15×110 Kabolt, 44mm offset, custom tuned for Giant
Shock Fox Factory Live Valve, 165/45, custom tuned for Giant
Handlebar Giant Contact SLR XC Flat, composite, 760x35mm
Grips Giant XC Pro S:32mm, M:32mm, L:34mm, XL:34mm
Stem Giant Contact SL XC, 35mm S:60mm, M:70mm, L:70mm, XL:70mm
Seatpost Fox Transfer Factory, dropper, remote S: 125mm travel / 30.9 x 363.5mm M: 150mm travel / 30.9 x 418.3mm L: 150mm travel / 30.9 x 418.3mm XL: 175mm travel / 30.9 x 475.1mm
Saddle Fi’zi:k Antares R5 with K:ium rails
Pedals N/A
Shifters SRAM XX1 Eagle AXS Rocker Paddle, 1×12
Front Derailleur N/A
Rear Derailleur SRAM XX1 Eagle AXS
Brakes Shimano XTR BR-MT9100, hydraulic, Shimano RT-64 rotors [F]180mm, [R]160mm
Brake Levers Shimano XTR BL-M9100
Cassette SRAM Eagle XG-1295, 10×52
Chain SRAM XX1 Eagle
Crankset SRAM XX1 Eagle, Quarq power meter, 32t S:170mm, M:175mm, L:175mm, XL:175mm
Bottom Bracket SRAM DUB, press fit
Rims DT Swiss XRC 1200 Spline 29
Hubs DT Swiss XRC 1200
Spokes DT Swiss XRC 1200, straight pull
Tires Maxxis Recon Race 29×2.4, foldable, TLR, EXO, tubeless
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Download PDF

Additional information

color

Black, Blue, Red

SIZING GUIDE AND GEOMETRY

  • S
      163 cm  to 172 cm
  • M
      171 cm  to 180 cm
  • L
      179 cm  to 188 cm
  • XL
      187 cm  to 198 cm

S M L XL
LOW | HIGH LOW | HIGH LOW | HIGH LOW | HIGH
A Seat Tube Length (mm) 381 432 483 533
B Seat Tube Angle (degrees) 73.0° 73.0° 73.0° 73.0°
C Top Tube Length (mm) 585 605 625 645
D Head Tube Length (mm) 100 115 130 150
E Head Tube Angle (degrees) 68.5° 68.5° 68.5° 68.5°
F Fork Rake (mm) 60 60 60 60
G Trail (mm) 90.1 90.1 90.1 90.1
H Wheelbase (mm) 1128.6 1149.8 1171.1 1192.7
I Chain Stay Length (mm) 445 | 460 445 | 460 445 | 460 445 | 460
J Bottom Bracket Drop (mm) 75 75 75 75
K Stack (mm) 621.5 635.5 649.4 668
L Reach (mm) 395 410.7 426.5 440.8
M Stand Over Height (mm) 719 735 772 811
N Handlebar Width (mm) 780 780 780 780
O Stem Length (mm) 50 50 60 70
P Crank Length (mm) 170 170 175 175
Q Wheel Size 27.5 27.5 27.5 27.5
