Description
Nothing beats the feeling of your first pedal bike. This two-wheeler comes with removable training wheels and makes it easy for kids to fall in love with cycling.
With 12-inch wheels, a lightweight aluminum frame, and removable training wheels, Animator makes learning to ride easy and fun. A shorter crank and narrow Q-factor make it easier to pedal, and short-reach brake levers give young riders confident stopping power. It also has an adjustable riding position and longer insertion depth for the seatpost, which makes it easier to achieve a perfect fit for kids of different heights. It comes with removable training wheels, so it’s easy to get started and then graduate to two wheels whenever they’re ready.
KEY PERFORMANCE FACTORS
Built for kids
Short crank length and narrow Q-factor make Animator easy to pedal, and a lightweight aluminum frame allows small children to have more control.
Kid-friendly features
Short-reach brake levers, lower stand-over height, protective stem pad and removable training wheels make it fun and safe for kids learning to ride a pedal bike.
Durable
ALUXX aluminum frame material provides long-lasting reliability, backed by a lifetime warranty on the frame.
| Sizes | One size |
| Colours | Black |
| Frame | ALUXX grade aluminium |
| Fork | High-tensile steel |
| Handlebar | Giant Kids, middle high, 480mm width |
| Stem | alloy quill, 25.4x40mm |
| Seatpost | alloy, 25.4x180mm |
| Saddle | Giant Kids |
| Pedals | Platform |
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Brakes | alloy, direct pull, drum brake |
| Brake Levers | alloy junior, adjustable reach |
| Cassette | 16T |
| Chain | KMC C410 |
| Crankset | alloy forged, 26t, 70mm |
| Bottom Bracket | Loose ball |
| Rims | Giant Kids 12″, alloy |
| Hubs | nutted, 16h |
| Spokes | 14g |
| Tires | Innova IA-2094, 12×2.25 |
| Extras | training wheels, bell, protective pad |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
Download PDF
Additional information
| color | Black, Blue, Red |
|---|
SIZING GUIDE AND GEOMETRY
| A | SEAT TUBE LENGTH (mm) | 185 |
| B | SEAT TUBE ANGLE | 73.0° |
| C | TOP TUBE LENGTH (mm) | 302 |
| D | HEAD TUBE LENGTH (mm) | 90 |
| E | HEAD TUBE ANGLE | 71.0° |
| F | FORK RAKE (mm) | 35 |
| G | TRAIL (mm) | 80.7 |
| H | WHEELBASE (mm) | 614 |
| I | CHAIN STAY LENGTH (mm) | 257 |
| J | BOTTOM BRACKET DROP (mm) | 28 |
| K | STACK (mm) | 287 |
| L | REACH (mm) | 214 |
| M | STAND OVER HEIGHT (mm) | 344 |
| N | HANDLEBAR WIDTH (mm) | 470 |
| O | STEM LENGTH (mm) | 40 |
| P | CRANK LENGTH (mm) | 89 |
| Q | WHEEL SIZE | 12″ |
TECHS & FEATURES
